Home ProductsTruck Air Spring

Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192

Certification
china Yitao Air Spring Group certification
china Yitao Air Spring Group certification
I'm Online Chat Now

Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192

Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192
Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192

Large Image :  Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192

Product Details:
Place of Origin: China
Brand Name: YITAO
Certification: IATF16949
Model Number: 1V 9192/1V9192
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: Negotiable in person
Packaging Details: Carton
Delivery Time: 1 ~ 30 days
Payment Terms: T/T
Supply Ability: 5000pieces/Month

Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192

Description
OE Numbe8r: W01-358-9192,1R12-167,910-19P326,AS-509-9192,352-9192,90557086 OE NO2: 90557135,90557108,90557136,8326,AS-0038,0046,B6295
YITAO Number: 1V 9192/1V9192 Type: Truck Air Spring
Application: For Truck Air Suspension Condition: Brand New
Warranty: 12 Months Typical Shipping Time: 3-10 Days
Sealing Configuration: Press-fit Cover Plate + Flange Material: Natural Rubber
Piston Material: Plastic Packing: Neutral Packing Or Customized Packing
Highlight:

Truck Air Spring replacement part

,

Firestone air spring AS-509-9192

,

Taurus truck air suspension component

Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192
Product Overview

Manufactured to specifications matching Firestone W01-358-9192/Taurus AS-509-9192, this air spring fully replaces the original equipment and provides your truck with a comfortable and stable ride.

Cross References
Brand Reference Numbers Numbering Discrepancy
Firestone W01-358-9192 W01-358-9192
Goodyear 1R12-167 1R12-167
Contitech 910-19P326 910-19P326
Taurus AS-509-9192 AS-509-9192
Dayton 352-9192 352-9192
Neway 90557086 / 90557135 / 90557108 / 90557136 90557086 / 90557135 / 90557108 / 90557136
Triangle 8326 8326
Watson&Chalin AS-0038/0046 AS-0038/0046
Hendrickson B6295 B6295
Technical Specifications
Specifications Parameters
Outer diameter φ255
Weight To be updated
Package Dimensions 27*27*45cm
Natural height 634mm
Maximum height 600mm
Minimum height 197mm
Extended Height 597mm
Compressed Height 201mm
Top Plate Width 231mm
Piston Width 260mm
1V 9192/1V9192 Truck Air Spring Drawing
Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 0
W01-358-9177 1R14-028 Product Images
Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 1
Images shown are for reference only. Actual product may vary slightly.
Factory Showcase
Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 2 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 3 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 4 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 5 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 6 Truck Air Spring Taurus AS-509-9192 Firestone W01-358-9192 7
Delivery Information
  • Delivery Time: Orders are typically shipped after payment is received. Depending on order size, shipment will be completed within 1-30 business days
  • Packing Method: Brown carton packing; we can also pack according to your requirements.
  • Shipping Marks: Generally display weight and size. We can also make shipping marks according to your requirements.
  • Transportation Methods: Sea transportation, air transportation, express delivery, railway transportation and various combined transportation methods.
  • International Transport Notes: Due to the international transportation, we need to pack according to strict requirements to avoid damage to the goods. If the logistics information is stagnant during transportation, please wait patiently. If you have any questions, please feel free to contact us.
Frequently Asked Questions
  • IS THE SAMPLE AVAILABLE?
    Yes, usually we send the samples by TNT, DHL, FEDEX or UPS. It will take around 3 days for our customers to receive them, but charge all customer will cost related to the samples, such as sample cost and airmail freight. We will refund our customer the sample cost after receiving its order.
  • WHAT IS YOUR WARRANTY TERM?
    Full container load orders receive 1% free spare parts. Export products carry a 12-month warranty from the date of shipment. For product failures within the warranty period, the customer is responsible for replacement part costs.
  • CAN I USE MY OWN LOGO AND DESIGN ON PRODUCTS?
    Yes, OEM is welcomed.
  • I CAN NOT FIND OUT THE ITEMS WHAT I WANT FROM YOUR WEBSITE, CAN YOU OFFER THE PRODUCTS I NEED?
    Yes. One of our service term is sourcing the products that our customers need, so please tell us the details information of the item.
