1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449

1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449
1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449

Large Image :  1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449

Product Details:
Place of Origin: China
Brand Name: YITAO
Certification: IATF16949
Model Number: 1V 6042
Payment & Shipping Terms:
Minimum Order Quantity: 50
Price: Negotiable in person
Packaging Details: Carton
Delivery Time: 30
Payment Terms: T/T
Supply Ability: 5000pieces/Month
Contact Now

1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449

Description
OE Number: W01-358-8829,1T15M-6,910-16P449,1R12-405,566-24-3-110,566-242-595-00035 OE No. 2: 8449,3934699,8084296,8079902,20413888,38829CPP,SC2757
Type: Truck Air Spring Application: For Truck Air Suspension
Packing: Neutral Packing Or Customized Packing Warranty: 1 Year
Condition: New Minimum Order Quantity: 50 Pieces
Sealing Configuration: Press-fit Cover Plate + Flange Material: Rubber
Piston Material: Plastic
Highlight:

1V 6042 truck air spring

,

truck air spring with warranty

,

Fierstone W01-358-8829 compatible air spring

1V 6042 Truck Air Spring Suitable for Firestone W01-358-8829/Goodyear R12-405/Contitech 910-16P449
Product Overview

YITAO 1V 6042 truck air spring is manufactured with reference to the specifications of Firestone W01-358-8829, which can completely replace the original air spring, providing a comfortable and stable driving environment for your truck.

Cross References
Brand Reference Numbers Numbering Discrepancy
Firestone W01-358-8829 / 1T15M-6 W013588829 / 1T15M6 / :W013588829 / :1T15M6
Contitech 910-16P449 91016P449 / :91016P449
Goodyear 1R12-405 / 566-24-3-110 1R12405 / 566243110 / :1R12405 / :566243110
Goodyear 566-242-595-00035 56624259500035 / :56624259500035
Airtech 38829CPP :38829CPP
Load Guard SC2757 :SC2757
Triangle 8449 :8449
AB Vovo 3934699 / 8084296 3934699 / 8084296 / :3934699 / :8084296
AB Vovo 8079902 / 20413888 8079902 / 20413888 / :8079902 / :20413888
Technical Specifications
Specifications Parameters
Natural height 574mm
Maximum height 524mm
Minimum height 145mm
Extended Height 575mm
Compressed Height 150mm
Top Plate Width 231mm
Piston Width 231mm
Outer diameter φ255
Weight 6.489 kg
Package Dimensions 28*28*46.5cm
Product Drawing
1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 0
Delivery Information
Category Details
Delivery Time Orders are typically shipped within 30 business days after payment is received
Packing Brown carton packing; we can also pack according to your requirements
Marks Generally display weight and size. We can also make shipping marks according to your requirements
Transportation Method Sea transportation, air transportation, express delivery, railway transportation and various combined transportation methods
International Transport Due to international transportation, we need to pack according to strict requirements to avoid damage. If logistics information is stagnant during transport, please wait patiently. Contact us with any questions.
Product Images
1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 1 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 2 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 3 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 4 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 5 1V 6042 Truck Air Spring Suitable for Fierstone W01-358-8829/Goodyear R12-405/Contitech 910-16P449 6
Images shown are for reference only. Actual product may vary slightly.
