Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363

Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363

Large Image :  Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363

Product Details:
Place of Origin: China
Brand Name: YITAO
Certification: IATF16949
Model Number: 1V 9648
Payment & Shipping Terms:
Minimum Order Quantity: 50 pieces
Price: Negotiate
Packaging Details: Carton
Delivery Time: 5-8 Work Days
Payment Terms: T/T
Supply Ability: 500pieces/Month
Contact Now

Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363

Description
Main Material: Natral Rubber Product Name: Rolling Bobe Air Spring
Application: Truck Suspension Spring Replacement Firestone NO.: W01-358-9648 W013589648 W01 358 9648
Operation: Gas-filled Package Dimension: 28*28*46.5cm
Net Weight: 7.439kg Other Name: Air Spring, Air Bag Suspension, Airide Springs
Highlight:

Air Ride Suspension W01-358-9648

,

W013589648 Firestone Air Ride Springs

 firestone air ride springs W01-358-9648 W013589648 For Triangle 8456 6363



Cross references
Automann
1DF23-P1058 1DF23P1058 1DF23 P1058
Firestone No.
W01-358-9648 W013589648 W01 358 9648
Firestone Style
1T15XNR-5 1T15XNR5 1T15XNR 5
FleetPride
AS9648
Triangle
AS-81068 AS 81068 AS 81068 8456 6363
TRP
AS10683
Primeride
AS PR9MR16 9648
Goodyear
1R12-538
Goodyear Flex No.
566243163
Road Choice
AS9648
Original parts
Navistar/Fleetrite
1R12-1057
Navistar/Fleetrite
2027911C3
Navistar/Fleetrite
2027911C2
Navistar/Fleetrite
2027911C1


Technical Parameters



Extended Height: 22.00

Compressed Height: 5.90

Top Plate Width: 9.00

Piston Width: 10.00

Bolt or Stud 1/2-13

Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 in Pistons

Air Inlet 1/4 N.P.T

Combination Stud/Air Inlet Stud Outside Thread is 3/4-16

Studs Inside Thread (Air Inlet) is 1/4 N.P.T.



Is it worth getting air bag suspension?


Take a look of some of the benefits of air suspension: More driver comfort due to the reduction in noise, harshness, and vibration on the road that can cause driver discomfort and fatigue. Less wear and tear on the suspension system due to reduced harshness and vibration of heavy-duty driving



About Yiconton



We are the biggest manufacturer of air suspensions parts in China. Our products have been imported worldwide. We can provide you with quality products and good service.

Our warranty is valid for 2-years limited from the shipping date. If it is within the warranty period, the factory will provide our FREE technical support and will replace the products for you.



Product picture



Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 0Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 1

Factory Showcase
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 2
Factory Overlook
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 3
Quality Control Inspection
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 4
Manufacturing Equipment
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 5
R&D Center
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 6
Assembly and Forming
Firestone Air Ride Springs W01-358-9648 W013589648 For Triangle 8456 6363 7
Vulcanization Shop
Delivery Information
  • Delivery Time: Orders are typically shipped after payment is received. Depending on order size, shipment will be completed within 1-30 business days
  • Packing Method: Brown carton packing; we can also pack according to your requirements
  • Shipping Marks: Generally display weight and size. We can also make shipping marks according to your requirements
  • Transportation Methods: Sea transportation, air transportation, express delivery, railway transportation and various combined transportation methods
  • International Transport Notes: Due to international transportation requirements, we pack according to strict standards to avoid damage. If logistics information is stagnant during transportation, please wait patiently. Contact us with any questions
Frequently Asked Questions
IS THE SAMPLE AVAILABLE?
Yes, we typically send samples via TNT, DHL, FEDEX or UPS. Delivery takes approximately 3 days. Customers are responsible for sample costs and airmail freight. Sample costs will be refunded after order placement.
WHAT IS YOUR WARRANTY TERM?
Full container load orders receive 1% free spare parts. Export products carry a 12-month warranty from the shipment date. For product failures within the warranty period, customers are responsible for replacement part costs.
CAN I USE MY OWN LOGO AND DESIGN ON PRODUCTS?
Yes, OEM services are welcomed.
I CANNOT FIND THE ITEMS I WANT FROM YOUR WEBSITE, CAN YOU OFFER THE PRODUCTS I NEED?
Yes. We provide product sourcing services for our customers. Please provide detailed information about the items you require.
Contact Us
Feel free to reach out. We'll get back to you within 24 hours (or sooner if we can!) and are excited to work with you.
