Truck Rubber Air Spring for Scania 1379392 1402423

Certification
China Guangdong Yiconton Air Spring Co., Ltd. certification
China Guangdong Yiconton Air Spring Co., Ltd. certification
I'm Online Chat Now

Truck Rubber Air Spring for Scania 1379392 1402423

Truck Rubber Air Spring for  Scania 1379392 1402423
Truck Rubber Air Spring for  Scania 1379392 1402423 Truck Rubber Air Spring for  Scania 1379392 1402423 Truck Rubber Air Spring for  Scania 1379392 1402423

Large Image :  Truck Rubber Air Spring for Scania 1379392 1402423

Product Details:
Place of Origin: Yunfu City,Guangdong Province,China
Brand Name: YICONTON
Certification: ITAF16949
Model Number: 1V0500
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Neutral Carton Box
Delivery Time: 5-7 Work Days
Payment Terms: T/T
Supply Ability: 500pcs/month

Truck Rubber Air Spring for Scania 1379392 1402423

Description
Material: Rubber+Steel Color: Black
Type: Truck Air Spring Truck Model: Scania
OEM No.: 1379392 1402423 Weight: 13.667
Packing Size: 29*29*42 Brand: YICONTON

Truck Rubber Air Spring for Scania 1379392 1402423



Technical parameters



Screw Bolt / Stud

Top Cover Plate screw bolt / Stud Tooth :2 pcs M12X1.5

Distance Between Two Stud :144 mm

Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : M16X1.5.

Distance Between Air inlet and Stud: 177 mm and 33 mm

Cover Plate

Top Cover Plate Diameter: Ø286 mm

Rubber Bellows

Rubber Bellows Natural Diameter: 330 mm

Rubber Bellows MAX Height : 797 mm

Rubber Bellows MIN Height :235 mm

Working stroke : 562 mm

Bumper block / Buffer block

Without Bumper Block

Bottom Piston

Bottom Piston Diameter : Ø230 mm

Bottom Piston Height :210 mm

Piston Bolt

Piston Bolt Tooth : M16X2.0 and Ø16

2 pieces of Bolt

Distance Between Two Bolt : 70 mm

Description

Cross Reference:

OE No.:1379392, 1402423Year: 2003-, 1980-1988, 1995-, 1988-1996
Used in vehicles:SCANIAModel: 3 - series, 2 - series, 4 - series, P,G,R,T - series
Products Name: air spring suspension bagWarranty: 1 year
Brand: YICONTONCertificate: ISO/TS/6949:2009
MOQ: 10pcs/orderOrder No.: 1V 0500



Other OEM No.

Firestone :W01-095-0500
Contitech :4913NP02
Goodyear :1R14-753
Phoenix :1D28H-16
Taurus :KR625-16
Dunlop FR :D14B42
CF Gomma :1T19E-93
Airtech :132122/34913K
Granning :16105
WABCO :9518147530
Meritor :MLF7081
Scania :1379392/1402423

Truck Rubber Air Spring for  Scania 1379392 1402423 0
Truck Rubber Air Spring for  Scania 1379392 1402423 1
Truck Rubber Air Spring for  Scania 1379392 1402423 2



Our Strength

Truck Rubber Air Spring for  Scania 1379392 1402423 3


FAQ


1.IS THE SAMPLE AVAILABLE?
YES,Usually we send the samples by TNT,DHL,FEDEX or UPS,it will take around 3 days for our customers to receive them,but charge all customer will cost related to the samples, such as sample cost and airmail freight.We will refund our customer the sample cost after receiving its order.
2.WHAT IS YOUR WARRANTY TERM?
Our company offer 1% free spare parts to FCL order.There is a 12months warranty for our export products has run outfrom the date of the shipment.If warranty ,our customer should pay for the replacement parts.
3.CAN I USE MY OWN LOGO AND DESIGN ON PRODUCTS ?
YES,OEM is welcomed.

4.I CAN NOT FIND OUT THE ITEMS WHAT I WANT FROM YOUR WEBSITE,CAN YOU OFFER THE PRODUCTS I NEED?
YES.One of our service term is sourcing the products that our customers need,So please tell us the details information of the item.
